EMX

EMX LR-650-TX Long Range Transmitter Remote

SKU:
LR-650-TX
Write a Review
  • Usually Ships Following Business Day
  • Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

Open your garage door from up to 450 feet away with the EMX LR-650 transmitter from Action Industries. The “LR” in EMX LR-650 refers to the device's long range capabilities as a gate and garage door opener remote when used with the EMX LR-650-RX receiver. This remote operates on a 315 MHz frequency with 68 billion possible codes to ensure unauthorized users can’t access the opener. Replace your current short range remote with the EMX LR-650 to ensure access to your facility from long distances. EMX’s LR-650 can be used for a wide variety of home automation products, including garage door openers, lights, gates, doors, and more.

Features:

  • LR-650-TX long range transmitter

  • Use on garage door openers, gate openers, lights, doors, and more

  • Used with the LR-650-RX Receiver

  • 4 output modes: 1 sec, 4 sec momentary, toggle, and latch

  • Single button transmitter

  • 68 billion possible codes

  • 450-feet open-air operation range

  • Receiver current draw as low as 8mA making it suitable for solar applications

  • Key chain ring

  • Flashing LED indicator

Specs:

  • Operating frequency: 315 MHz

  • Operating voltage: 11 - 24 VDC/AC

  • Operating distance: 450 feet open air, 1100 feet with optional dipole antenna

  • Operating temperature: -4°F to +162°F

  • Current Draw: 15 mA @ 12 VDC (standby) / 45 mA @ 12 VDC (activated)

  • Sensitivity: -87 dBm (typical)

  • Data Format: PWM

  • RF Codes: 68 billion

  • RF Channels: 1

  • Number of Stored Transmitter Codes: 15 FIFO

  • Receiver Outputs: Form “C” relay output (NO/COM/NC)

  • Output Modes (Programmable): 4 sec momentary (default), 1 sec momentary, toggle, or latch

  • Connectors: Quick connect screw terminals

  • Case Material: High-impact ABS plastic

  • Approvals: FCC

Product Manual
