Sommer 2060 EVO+ 3/4HP Direct Drive Model S10256

QUALITY:

• Extremely quite and smooth garage door operation

• Reliable opener system because of only one moving part

• DC- motor is directly attached to the door providing maximum lifting force

• Lifetime Warranty on motor

• 6-year warranty on parts

• 2- year warranty on accessories (photo sensors, wall station, transmitters)

• LED technology: durable, efficient lighting

• Made in Germany

• Standby power <2 Watt. (corresponds to approx. $2.00 in energy cost per year)

SAFETY:

• Advanced object and force detection system

• Automatic locking and counter pressure in case of an attempted break-in

• Very secure 128 bit encryption radio technology (rolling code)

• Emergency release can be locked or unlocked in any position

• Optional battery backup for emergency operation in the event of a power failure

• Optional locking magnet for motor, locks in any position

FLEXIBILITY:

• Rail is long enough for 8ft. tall doors

• Easy shortening or lengthening of the track possible (Available extensions: 21.5” and 43”)

• Countless ad on accessories e.g. Memo transmitter memory, Senso humidity sensor, Lock locking magnet, Lumi evo+ additional LED lighting, buzzer ...

• Removable carriage without track disassembly

INTELLIGENCE:

• Automatic learning process: self-learning force curve with continual adjustment

• Optimal speed profile for quick opening and secure closing

• Automatic optimization of door operation through direct entry of measured operating forces

• Active braking for moving doors

• Countless setting and inquiring options via SOMlink

SPECIFICATIONS:

• Operator – 2060 EVO+

• Motor Power – 600 N (3/4 HP)

• Standard Door Height –7 and 8 foot tall doors

• Overall Length – 140 inches

• Max. Door Height With Extensions –23 feet

• Max Travel Speed – 9/4 inch/sec

• Power Consumption (Standby) – <2 W

• Number Of Programmable Remote Buttons – 40

• Connection For Warning Light – Yes (DC 24 V/25 W)

• Radio Frequency – 922.5 MHz

• Homelink Compatible – Yes

• Shipping Weight – 28.2 Lbs

• Shipping Dimensions – 44.5 in x 7.5 in x 5 in

• Connection For Safety Edge – Yes

ACCESSORIES:

• LOCK - Locking magnet which mechanically blocks the motor in any position up to an attack force of 660lbs. (certified), thereby enhancing the existing break-in protection. (mechanical locking mechanism of the opener

• SENSO – For recording air humidity and temperature in the garage. The carriage automatically opens and closes the door a bit if necessary, ensuring perfect air circulation. This reduces the risk of mold formation.

• MEMO – Used to expand the memory to 450 transmitter commands. If service is required, the saved transmitters can be easily moved to a new garage door opener

• MOTION SENSOR – Detects motion in the garage and automatically activates the LED lighting. Motion sensor attaches to the door arm and connects to the motor carriage.

• BUZZER – Two functions in one product: The alarm buzzer recognizes a break-in attempt and outputs a loud signal tone. The warning buzzer outputs an acoustic signal during the closing process.

• LUMI EVO+ – Additional LED lighting for the control unit. It is switched in parallel with the lighting in the carriages and can be easily switched on and off using the transmitter.

• ACCU BATTERY PACK – Integrated in the control unit, the battery pack will supply power during power outages. Reliable NiMH battery backup solution. Life cycle up to 10x greater compared to a Lead-Acid battery

• RELAY – Additional relay for additional switching of a garage or courtyard light.

• SOMLINK – The SOMlink service module offers a wide variety of setting options for the new SOMMER products on your smartphone or tablet by means of the Web app.

• PEARL – 4-button transmitter using 922.5 MHz frequency

• PEARL TWIN – 2-button transmitter using 922.5 MHz frequency

• Holder PEARL – Holder for installing the transmitter in a car or on the wall – Includes double sided tape.

• TELECODY+ (WIRELESS KEYPAD – The SOMMER Telecody + – wireless keypad allows you to operate your SOMMER garage door opener by simply entering your personal code.

• ENTRAPIN+ (WIRELESS KEYPAD) – The SOMMER Wireless Keypad allows you to operate your SOMMER garage door opener by simply entering your personal code. Dependable and easy access solution for anyone who uses the garage as a primary home entrance.

• SOMCOM2 (RADIO RECEIVER IN HOUSING) – The external receiver enables the use of the SOMMER transmitter with other manufacturer’s brands. Can also be used for gate operators.

• SOMTOUCH (WIRELESS WALL BUTTON) – The battery operated Wireless wall button can also be used as a remote control. Operates up to 2 different garage door openers, No need to run wires to the garage door opener
