    Optex OVS-01GT Vehicle Presence Sensor

    SKU: OVS-01GT

    Detect any vehicle and automatically open residential gates with the OVS-01G from Optex America available from Action Industries. This Optex vehicle sensor connects to Swing, Barrier Arm, and Slide Gates to reliably detect both large and small vehicles while ignoring human traffic. The device installs 2 to 3 feet above ground on a pole or post and wires directly into residential and commercial gate operators. Adjustable Microwave and Ultrasonic Detection Patterns allow you to customize the detection area for your residential gate. The OVS-01G eliminates the need for an additional loop or loop detector meaning no more cutting concrete for installation. Microwaves are used for long-range detection while Ultrasonic waves are used for short-range detection. Choose from 5 sensitivity settings to make the OVS-01G work best for your installation.

    Product Highlights:

    • Reliably detects both small and large vehicles

    • Two customizable detection patterns

    • Utilizes Microwave and Ultrasonic detection patterns

    • Microwave Detection Range: 6-1/2 - 18 ft.

    • Ultrasonic Detection Range: 2 - 3-1/4 ft.

    • Mounts 2-3 feet off the ground

    • 8 range settings, 5 sensitivity settings (including options to ignore human movement

    • Easy installation

    • No need for additional loop detectors

    • Voltage 12-24VDC

    Applications Include:

    • Slide Gate - Free exit

    • Slide Gate - Vehicle protection

    • Slide Gate - Shadow loops

    • Swing Gate - Vehicle protection

    • Barrier Arm - Activation (ticket/RFID/keypad activation)

    • Industrial Doors - vehicle protection

    Product Specs:

    • Detection Method: Microwave (Doppler shift and FMCW)/Ultrasonic combination

    • Frequency: Microwave: 24GHz, Ultrasonic: 56KHz

    • Response Time: 500msec

    • Power Supply: 12-24VDC

    • Current Consumption: Max 200mA (at 24VDC) with Heater ON; Max 80mA when Heater is OFF

    • Output: Relay output DC30V, 0.3A (NO/NC selectable)

    • Microwave Detection Range: 6.5 ft. to 18 ft. programmable maximum range

    • Ultrasonic Detection Range: 2 ft. to 3.5 ft. programmable maximum range

    • Detectable Vehicle Speed: 1.24mph - 12.43mph

    • Operation Temperature: -22°F to 122°F
