Photo Eye Reflector, NIR Plus Retro

EMX’s NIR Plus is a Retro-Reflective garage door or gate operator Photoeye. The NIR Plus has an extended range of 45 feet to provide better performance in the rain and snow compared to the standard NIR model. The NIR Plus is ideal for heavy duty installations and has a watertight construction that protects it from the elements. It’s retro-reflective style uses a single transmitter and receiver with a 3-inch reflector disk installed on the opposite wall, door jamb, or post. Each NIR Plus Photoeye comes with a reflector hood to protect the reflector from debris, a mounting bracket, and metal transmitter/receiver hood.

Features:

• Retro-reflective photoeye with an extended 45-feet range

• Provides better performance in rain and snow

• Low current draw of 28mA is ideal for solar and low voltage applications

• Watertight package protects from the elements and vandalism

• Output relay is normally energized, if NIR Plus loses power it will fail into detect mode

• Installation hardware, bracket, and instructions are included

• 6 ft. cable

• Two LED indicators

• Sensitivity adjustment

• Flexible voltage: 12V AC/DC to 230V AC, 28mA Current Draw Standby, 15mA Current Draw Detect

• Relay Output: 3A 24V, 1A 220V Normally Energized

• Compact size:

• 2” High

• 2” Deep

• 0.70” Wide
