Action Hardware

E900 Hardware Kit for One Piece Garage Doors

SKU:
104-0222
Write a Review
  • Usually Ships Following Business Day
  • Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

Adjust your One-Piece Garage Door without having to remove the springs with the Holmes Adjusta-Matic E900 one-piece garage door hardware kit from Action Industries. This single-panel garage door hardware kit allows you to stretch garage door springs to the proper fit without having to remove them. Replace a worn or old kick assembly and lower jamb connector, or replace the entire assembly with our one-piece jamb hardware kit. The universal Adjusta-Matic springs adjustor works with C hooks (single spring) or W hooks (double springs), and is compatible with automatic garage door openers for single-panel doors.

Features:

  • Universal hardware kit for single-panel garage doors

  • Adjusts door springs without having to remove springs

  • Compatible door heights: 6 ft. 10 inches to 7 ft. 4 inches

  • Compatible door widths: 6 ft. to 16 ft.

  • Maximum weight capacity: 350 lbs

  • Heavy duty steel parts construction

  • Use with manual or automatic garage door openers

Kit Contents:

  • 1x - #6 x 18 rope

  • 2x - 1/4-20 x 4 Carriage Bolt

  • 6x - 3/8 x 3-3/4 Hex Lag Screw

  • 6x - 5/16 x 1-1/2 Hex Lag

  • 2x - A-M Lower Spring Assy

  • 1x - A-2 Reg Slide Bolt

  • 2x - Door Stop Acc Kit

  • 1x - Flanged Ferrule

  • 1 x - Handle w/ Black Grip

  • 1x - HHI Limited Warranty

  • 1x - Instruct Sheet RHJ Wood

  • 1x - Tassle

  • 1x - Large Poly Bag Size

  • 1x - Fastener Bag w/ Bumpers

  • 2x - 1/4-20 x Oval Head Drive

  • 2x - 1/4-20 x 1-1/2 Carriage

  • 2x - 1/4-20 Hex Nut 3/8

  • 4x - 10 GA x 1-3/4 Plywood

  • 4x - 11 GA x 1-3/4 Pallet

  • 6x - 5/16-18 Heavy Hex Nut ZP

  • 2x - 10-24 Hex Nut

  • 4x - 8 D Duplex Nails

  • 2x - Rubber Bumper - White

  • 1x - Screw Eye Small

  • 6x - Special 3/8 Washer

  • 2x - Washer 1/4 Cut

  • 6x - 5/16-18 x 3/4 Hex Cap

  • 2x - 10-24 x 1-1/2 FH Slot

  • 1x - Small Poly Bag Size
