EMX OWL Vehicle Motion & Presence Sensor, includes 32 ft (10 m) cable and mounting screws

The EMX OWL is a professional vehicle motion and presence sensor designed for automatic doors, industrial gates, high-speed doors, and loading dock applications. Using advanced microwave and infrared detection, it provides reliable door activation and area protection in one compact unit, with adjustable settings for direction detection, filtering, hold time, and presence zones.

Specifications

• Combines vehicle motion detection and presence detection in one sensor
• Designed for high-speed doors, loading dock doors, industrial gates, warning lights, audible alarms, and pull cord replacement
• Advanced microwave and infrared technology with adjustable detection fields
• Configurable outputs for NO or NC relay operation
• Remote-adjustable settings for presence area, direction detection, filtering, and hold time
• Helps reduce unnecessary door cycling by distinguishing vehicle traffic from pedestrian or parallel traffic
• Mounting height: 11.5' to 21.3'
• Supply voltage: 12 to 24 VDC/AC
• Maximum current draw: 150 mA at 12 VDC
• Operating temperature: -4°F to 140°F
• Operating humidity: Below 80%
• Dimensions: 9" x 5" x 5"
• Connection: 32' 8-conductor cable directly from sensor
• Weight: 2.87 lbs.
• Environmental rating: IP65
• Vertical directionality: 16° to 32° wall or ceiling mount
• Horizontal directionality: +/- 10°
• Microwave operating frequency: 24.150 GHz
• Microwave detection range: Maximum 23' range x 19.7' width, dependent on sensor height and housing angle
• Microwave relay contact rating: Maximum 48 VDC, maximum 300 mA
• Microwave relay hold time: Typical 500 ms
• Adjustable microwave tilt angle: -10° to 25°
• Infrared detection range: Maximum 18' range x 26.2' width, dependent on sensor height and housing angle
• Infrared relay contact rating: Maximum 48 VDC, maximum 300 mA
• Infrared relay hold time: 30 seconds to infinite, adjustable
